What Are My Choices?

Scroll down to see what's available

Profile and Size

The system profiles which are available in double and triple glazing.

Premium Profiles

Economy Profiles

Inside Profiles

Timber Sizes

BAL Rating


Triple Glazed	U_w Value (Window)	U_g Value (Glass Only)	Visual Transmission Glass
Premium Aluminium-Clad ^{IV78 Slim1}	0.8 - 1.1 W/m²K	0.6 W/m²K	74%
Timber Protect ^{IV78 Protect}	0.8 - 1.1 W/m²K	0.7 W/m²K	74%
Full Timber ^{IV78 Holz}	0.8 - 1.1 W/m²K	0.7 W/m²K	74%
Double Glazed	U_w Value (Window)	U_g Value (Glass Only)	Visual Transmission Glass
Premium Aluminium-Clad ^{IV68 Slim3}	1.3 - 1.6 W/m²K	1.1 W/m²K	82%
Timber Protect ^{IV68 Protect}	1.3 - 1.6 W/m²K	1.1 W/m²K	82%


	Economy Double & Triple Glazed Windows	Premium Double and Triple Glazed Windows
3d Hardware System & 3d Adjustment	✔	✔
Durable Powder Coating	✔	✔
Suitable For Passivhaus	✔	✔
Timber Choice	Select Timber - Spruce, Red Grandis, Larch & Oak
*Doepfner does not use finger-jointed timber
Timber Stain Colours Available	✔	✔
Hidden Hinges	✖	✔
Heritage / Colonial Bars	✔	✔
Powder Coating Colour Options	Standard Colours	Standard Colours PM10 + PFS10
	PM10 (17 Colours)	Premium Colour Options
	PFS10 (17 Colours)	Fake Timber Desgins
	10 Year Warranty on Fading	Up to 30 Year Warranty on Fading
Shapes	Rectangular, Sloped Top, and Combinations	Rectangular, Sloped Top, Curved Top, Triangular, & Many Other Options
Glass	Advanced Swisspacer	Ultimate Swisspacer
	Size up to 6m2	Larger than 6m2 Possible
	Cavity Valve for High Altitudes (>800m)	Cavity Valve for High Altitudes (>800m)
	Timber Instead of Glass Available	Timber Instead of Glass Available
Price Range per sqm *Windows Only	$850-1150	$1250-1600


BAL Rating	Glazing Specs	Window/Door Frame Specs
Low	No special requirements.	IV78 Holz Full Timber may be used.
12.5	Laminated or toughened grade A safety glass. Minimum 4mm toughened and Minimum 6mm laminated.	IV78 Slim1 Aluminium-clad must be used.
19	Toughened grade A safety glass - Minimum 6mm.	IV78 Slim1 Aluminium-clad must be used.
29	Toughened grade A safety glass - Minimum 6mm. All glass within 400mm of ground or other structures with 18 degrees of horizontal must be screened externally with metal screens. LAROS normally complies with this requirement by replacing the lower 400mm of glass in a window/door by aluminium clad timber.	IV78 Slim1 Aluminium-clad must be used.
40	No fenestration solution available.

CONFIGURATIONS

This will help illustrate the more common configurations available to you.

NOTE: ALL DRAWINGS ARE VIEWED FROM THE INSIDE

Fixed Windows

Tilt & Turn

French Tilt & Turn

Lift & Slide

Parallel Slide

Others

European Style

Tilt & Turn Configuration

CLOSED

TURN MODE

TILT MODE

Timber and Stain

All timber surfaces are coated with three specially formulated protective layers.

This innovative coating allows for a natural timber finish with never seen before durability. In addition, there is the option of staining your timber for a unique finish, or painting your timber with a wide range of RAL colours available.

Spruce

Larch

Oiled Larch

Oak

Note: These stains require regular maintenance due to not having a sealed surface. At least a yearly or half-yearly re-oiling is required.

Aluminium-Cladding

Aluminium cladding on the outside of your window acts as the perfect protective shield,
which can withstand even the harshest weather conditions.

The aluminium frames are fully welded and polished to perfection before the final powder coating is applied. This process ensures a perfectly seamless, high-quality optical and rainproof finish that maximises aesthetics and longevity.

RAL Colour - Premium 10

RAL Colour - Premium Select 10 (Timber)
